RSP 系列开关电源 35W单路输出
RSP31-35-5
723110.
| 技术参数: | 产品规格 | |||||||||
| 输入电压 | 88~264VAC 120~370VDC | 型号 | 输出 | 电压稳定度 | 负载稳定度 | 纹波系数 | 效率 | 订货号 | ||
| 交流电流 | 1A/220VAC | RSP31-35-5 | 5V/7A | ≤1% | ±2% | ≤2% | 77% | 723110 | ||
| 输入频率 | 50/60Hz | RSP31-35-9 | 9V/3.8A | ≤1% | ±1% | ≤1% | 77% | 723111 | ||
| 突波电流(25℃) | 30A/220VAC | RSP31-35-10 | 10V/3.5A | ≤1% | ±1% | ≤1% | 77% | 723112 | ||
| 启动、上升时间 | 500ms，100ms/220VAC | RSP31-35-12 | 12V/3A | ≤1% | ±1% | ≤1% | 78% | 723113 | ||
| 保持时间 | 10ms | RSP31-35-15 | 15V/2.3A | ≤1% | ±1% | ≤1% | 78% | 723114 | ||
| 过载保护 | 过功率保护 | RSP31-35-24 | 24V/1.5A | ≤1% | ±1% | ≤1% | 79% | 723115 | ||
| 短路保护 | 自动恢复 | RSP31-35-36 | 36V/1A | ≤1% | ±1% | ≤1% | 79% | 723116 | ||
| 过压保护 | 可恢复 | RSP31-35-48 | 48V/0.7A | ≤1% | ±1% | ≤1% | 79% | 723117 | ||
| 工作温度范围 | -25℃~+60℃，周围温度 |  | ||||||||
| 工作湿度范围 | 5~95%RH，无结露 | |||||||||
| 存储温度范围 | -40℃~+85℃，周围温度 | |||||||||
| 安全规范 | EN60950-1 | |||||||||
| 绝缘阻抗 | I/P-O/P:500VDC >100MΩ 25℃/70%RH | |||||||||
| 耐压 | I/P-O/P:2KVAC | |||||||||
| 电磁兼容抗扰度 | EN61000-4-2,3,4,5,6,8,11 EN55024 EN61204-3 | |||||||||
